Japanese Sanyo CD Mechanism – Equipped with a precision laser pickup assembly for superior disc reading accuracy.
Excellent Anti-Interference Performance – Strong error correction, stable operation, and resistance to damage.
Premium Construction – Sleek, minimalist aluminum alloy design for an elegant look and feel.
Smooth Playback – Ensures seamless CD loading and consistent performance.
High-Resolution Audio – Delivers detailed, natural sound reproduction.
Hi-Fi Compatibility – Works perfectly with professional and home stereo systems.
Compact & Stylish – Ideal for modern audio setups.
Core Components:
Decoding Chip: Taiwan Lingyang SPHE8204W
Memory Chip: M12L64A
Drive IC: HD5888A
Crystal Oscillator: JHX27.000
Op-Amps: JRQ4558 ×2, JRC4558M, JRC5532M ×3
Supported Media:
Discs: Audio CD, CD-R, CD-RW, WMA
USB (U Disk): WAV, FLAC, AAC, WMA, MP3, APE (up to 128 GB, USB 3.0 compatible)
Bluetooth: Version 5.3
Audio Outputs:
Digital: Optical / Coaxial
Analog: RCA
Balanced: XLR
Performance Metrics:
Signal-to-Noise Ratio (SNR): 125 dB
Total Harmonic Distortion (THD): 0.0008 %
Frequency Response: 20 Hz – 20 kHz (+0/−0.5 dB)
Reference Output Level: 2 V ± 3 dB (1 kHz)
Channel Separation: > 100 dB (1 kHz)
Type: Voltage-stabilized rectifier and filtering system
Transformer: 35 W high-power pure copper toroidal transformer
Ultra-low magnetic leakage
Strong, stable power reserve
Components:
6 × high-speed rectifiers
3 × high-precision voltage regulators
1 × rectifier bridge
6 × imported capacitors
Front Panel Material: Aluminum Alloy
Net Weight: 4.9 kg
