ZEN Streamis a true ground-up design by iFi — the hardware and software implementation is quite exceptional:
Two SuperSpeed USB3.0 portswithActive Noise Cancellation II
S/PDIF out with the iPurifier built-in
Power supply with Silent Power tech
iFi software developed with Volumio open-source as the starting point, then coded and optimised by us to achieve the purest streaming software bar none
These are some of the factors behind why theZEN Streamis at the cutting-edge handling PCM384/DSD256on LANandWiFi (802.11n, with 100Mbps on 5Ghz).
‘Exclusive’ for your ears only.
TheZEN Streamhas one of the mostfully-optimisedsoftware platforms in the world.
From the device’s drivers, to the kernel (the heart of the operating system), to the shell (which interfaces with the kernel), to the applications and the user interface — everything is fully optimised for seamless operation and excellent sonic performance.
An ingenious part of theZEN Stream’sdesign is the ability to select between ‘Exclusive’ modes – individual settings dedicated to specific modes of operation to deliver the purest possible performance. All other programs are shut down – to minimise ‘software jitter’ — an often overlooked aspect that negatively impacts the quality of computer audio playback.
This ensures that theZEN Streamis not merely a ‘jack of all trades’, but a master of all too.
All-in-one (AIO) covers all modes
Roon only – feature coming soon – ROON ready
Please note software updates may take 2-3 minutes. Please do not disconnect your device.
Who’s who of Streaming.
Hot off the press, theZEN Streamhas the following connectivity options:
Stream straight from Spotify/Tidal apps with Spotify Connect and Tidal Connect
Works with any DLNA certified streaming app (our own app is imminent!)
Integrated Airplay and Chromecast* – easy streaming from Apple and Android devices
ROON Ready functionality to be added in a future update.
Beneath the unassuming casework sits some serious horsepower in terms of both technologies and components:
Powerful 64-bit quad-core ARM Cortex microprocessor
USB and S/PDIF interfaces regulated by femto-precision GMT clock to eradicate jitter
Active Noise Cancellation II and iPurifier technologies for USB and S/PDIF interfaces respectively
Intelligent Ethernet switch controller
High-PSRR,low idle current, low-dropout voltage regulators with soft start
Synchronous 1.6MHz high-speed precision power supply controller
C0G capacitors and Taiyo Yuden and Murata low ESRinductors
This is a true hi-res device. It uniquely supports PCM up to 32-bit/384kHz over Wi-Fi as well as Ethernet cable, plus DSD up to 11.2MHz (DSD256). Highly unusual in a Wi-Fi streamer.
Our ‘exclusive modes’ give you individual settings dedicated to specific modes of operation to deliver the purest possible performance.
All-in-one This non-specific mode is great for all platforms, audio formats and devices.
DLNA streaming Select this mode to optimise performance when using the ZEN Stream with DLNA-compatible apps and devices.
NAA streaming Select this mode when using the ZEN Stream as a Network Audio Adapter in conjunction with Signalyst HQPlayer software.
Feature coming soon – ROON Ready ROON Ready functionality to be added in a future update. Select this mode when integrating the ZEN Stream into a ROON environment.
Tidal streaming If you are a subscriber to Tidal’s Masters Tier, this is the mode for you.
Use the ‘hotspot’ button on the front to join a Wi-Fi network.
Dual-band Wi-Fi reception supports 802.11a/b/g/n/ac for a fast, reliable wireless connection.
The circuit design has been painstakingly engineered to deliver superb sound, with processing muscle supplied by a 64-bit, quad-core ARM Cortex microprocessor.
The USB ports – both input and output – support the SuperSpeed USB3.0 standard and benefit from iFi’s Active Noise Cancelling technology to remove distortion from the audio signal.
Similarly, the coaxial S/PDIF output incorporates iFi’s iPurifier signal purifying technology.
Both of the two digital outputs – asynchronous USB and coaxial S/PDIF – that provide connectivity to an external DAC or an amp with digital inputs are regulated by iFi’s femto-precision GMT (Global Master Timing) circuitry to eradicate jitter from the digital audio signal.
Intelligent Ethernet. The device uses a high-performance Ethernet switch with a low-power integrated 5-Port Giga-PHY.
We’ve utilised high-PSRR, low idle current, low-dropout voltage regulators with soft start. This means maximised efficiency and minimised system noise.
Add to this, a synchronous 1.5MHz high-speed power supply controller for even great noise reduction and even less distortion.
Carefully chosen circuit components including discrete, high-grade surface-mounted devices such as TDK C0G multilayer ceramic capacitors and inductors from Taiyo Yuden and Murata add to the quality build of this product.
