Features
-
Dual AKM AK4497S DACs with fully balanced audio circuit
-
Discrete Class-AB headphone amplifier with transistor current boosting
-
Eight operating modes:
-
Streaming (Roon Ready, AirPlay)
-
Local playback (USB storage)
-
USB DAC
-
Bluetooth decoding
-
Optical decoding
-
Coaxial decoding
-
Single-ended line input
-
Balanced line input
-
-
Physically separated power, digital, and analog circuit boards
-
Built-in low-noise industrial-grade power supply with external DC power option
-
Multi-stage analog power supply with 14 LDO regulators
-
Dual femtosecond crystal oscillators for precise clocking
-
High-quality capacitors and silver-plated oxygen-free copper wiring
-
Dual-core X2000 processor and ESP32-S3 MCU for efficient system control
-
Multiple control methods: touch screen, knobs, remote, and FiiO Control App
-
10-band PEQ on all digital inputs
-
Multiple protection systems (temperature, overvoltage, overload, DC, overcurrent)
-
Wired and wireless connectivity (Gigabit Ethernet + dual-band Wi-Fi)
What's in the box
-
K15 ×1
-
AC power cord ×1
-
USB data cable ×2
-
Headphone plug adapter ×1
-
Remote control ×1
-
Fuse ×1
-
XLR4 decorative plug ×1
-
Battery ×2 (only for China, English, Japan regions)
-
Quick start guide ×1
-
Warranty card ×1
Specifications
Basic specifications
Color: Black/Silver
Dimensions: About 244.6x213x66.8mm
Weight: About 2100g
Hardware configurations
Master Control: X2000, ESP32-S3
DAC: AK4497S*2
USB: XMOS XU316
Headphone amplifier transistor: MJE243G/253G
Display: 3.93-inch LCD
Decoding specifications
USB DAC: 768kHz/32bit; DSD512 (Native)
Coaxial input: 192kHz/24bit; DSD64
Optical input: 96kHz/24bit
Local playback: 384kHz/32bit; DSD256
Headphone outputs
Output Power 1: L+R≥1400mW+1400mW (32Ω SE, THD+N＜1%, Ultra high gain mode)
Output Power 2: L+R≥3000mW+3000mW (32Ω BAL, THD+N＜1%, Ultra high gain mode)
Output Power 3: L+R≥180mW+180mW (300Ω SE, THD+N＜1%, Ultra high gain mode)
Output Power 4: L+R≥700mW+700mW (300Ω BAL, THD+N＜1%, Ultra high gain mode)
Streaming playback: 384kHz/32bit; DSD256 (DOP)
Line outputs
RCA output: L+R=2.4Vrms+2.4Vrms (1kHz@10kΩ)
XLR output: L+R=4.8Vrms+4.8Vrms (1kHz@10kΩ)
Audio parameters
Frequency response: 20Hz~80kHz, attenuation＜2.8dB
SNR: ≥122dB (A-weighted)
Noise floor: ＜5.3μV (A-weighted)
THD+N: ＜0.00054% (1kHz/-12dB@32Ω)
